YAMADA External Turning CBN Liner PCBN Inserts With Coating
Product Details:
| Place of Origin: | Shanghai, China |
| Brand Name: | YAMADA, YAMADA |
| Certification: | ISO9001,ISO14001 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 pieces |
|---|---|
| Packaging Details: | 10 pcs of PCBN insert in a PVC box, carton outer packing or as your requirement |
| Supply Ability: | 30000 Piece/Pieces per Month |
|
Detail Information |
|||
| Warranty: | 3 Years | Customized Support: | OEM, ODM |
|---|---|---|---|
| Place Of Origin: | Shanghai, China | Brand Name: | YAMADA |
| Usage: | External Turning Tool | Hardness: | >4500 HV |
| Coating: | Coating | Insert: | PCBN Insert |
| Brand: | YAMADA | Sample: | YES |
| Material Supplier: | GE And E6 | MOQ: | 1 PC |
| Production Time: | 15 Days | Machining: | Continue Or Interrupt |
| Applicated Workpiece: | Cast Iron | Shipment: | DHL,UPS,FEDEX |
| Certification: | ISO9001,ISO14001 | ||
Product Description
| PCD | ||||||
| appearance | shape | type | inscribed circle | thickness | Radius | Inner hole demeter |
| |
TNMM | TNMM160404 | 9.525 | 4.76 | 0.4 | 3.81 |
| TNMM160408 | 0.8 | |||||
| TNMM160412 | 1.2 | |||||
| TCGW | TCGW110302 | 6.35 | 3.18 | 0.2 | 3.4 | |
| TCGW110304 | 0.4 | |||||
| TCGT | TCGT110202 | 6.35 | 2.38 | 0.2 | 2.8 | |
| TCGT110204 | 0.4 | |||||
| TCMT080202 | 4.76 | 2.38 | 0.2 | 2.4 | ||
| TCMT080204 | 0.4 | |||||
| TCMT090202 | 5.56 | 2.38 | 0.2 | 2.8 | ||
| TCMT090204 | 0.4 | |||||
| TCMT110301 | 6.35 | 3.18 | 0.1 | 3.4 | ||
| TCMT110302 | 0.2 | |||||
| TCMT110304 | 0.4 | |||||
| TPGW | TPGW080202 | 4.76 | 2.38 | 0.2 | 2.4 | |
| TPGW080204 | 0.4 | |||||
| TPGW090202 | 5.56 | 2.38 | 0.2 | 2.8 | ||
| TPGW090204 | 0.4 | |||||
| TPGW110302 | 6.35 | 3.18 | 0.2 | 3.4 | ||
| TPGW110304 | 0.4 | |||||
| TPGW160404 | 9.525 | 4.76 | 0.4 | 4.4 | ||
| TPGW160408 | 0.8 | |||||
| TPGW160412 | 1.2 | |||||
| TPGT | TPGT110302 | 6.35 | 3.18 | 0.2 | 3.4 | |
| TPGT110304 | 0.4 | |||||
| TPGN | TPGN090204 | 5.56 | 2.38 | 0.4 | / | |
| TPGN090208 | 0.8 | |||||
| TPGN110302 | 6.35 | 3.18 | 0.2 | / | ||
| TPGN110304 | 0.4 | |||||
| TPGN110308 | 0.8 | |||||
| TPGN160302 | 9.525 | 3.18 | 0.2 | / | ||
| TPGN160304 | 0.4 | |||||
| TPGN160308 | 0.8 | |||||
| PCBN | |||||||
| appearance | shape | type | No of cutting edges | inscribed circle | thickness | Radius | Inner hole demeter |
| |
TNGA | X-TNGA160404 | 1 3 6 | 9.525 | 4.76 | 0.4 | 3.81 |
| X-TNGA160408 | 0.8 | ||||||
| X-TNGA160412 | 1.2 | ||||||
| X-TNGA160416 | 1.6 | ||||||
| TCGW | X-TCGW090202 | 1 | 5.56 | 2.38 | 0.2 | 2.8 | |
| X-TCGW090204 | 0.4 | ||||||
| X-TCGW110202 | 1 | 6.35 | 2.38 | 0.2 | 2.8 | ||
| X-TCGW110204 | 0.4 | ||||||
| TPGW | X-TPGW080202 | 1 | 4.76 | 2.38 | 0.2 | 2.3 | |
| X-TPGW080204 | 0.4 | ||||||
| X-TPGW090202 | 1 | 5.56 | 2.38 | 0.2 | 2.8 | ||
| X-TPGW090204 | 0.4 | ||||||
| X-TPGW090208 | 0.8 | ||||||
| X-TPGW110302 | 1 | 6.35 | 3.18 | 0.2 | 3.4 | ||
| X-TPGW110304 | 0.4 | ||||||
| X-TPGW110308 | 0.8 | ||||||
| X-TPGW160304 | 1 3 | 9.525 | 3.18 | 0.4 | 4.4 | ||
| X-TPGW160308 | 0.8 | ||||||
| X-TPGW160404 | 1 3 | 9.525 | 4.76 | 0.4 | 4.4 | ||
| X-TPGW160408 | 0.8 | ||||||
| TPGN | X-TPGN110304 | 1 | 6.35 | 3.18 | 0.4 | / | |
| X-TPGN110308 | 0.8 | ||||||
| X-TPGN160304 | 1 3 | 9.525 | 3.18 | 0.4 | / | ||
| X-TPGN160308 | 0.8 | ||||||
Packaging: Plastic box
Rose plastic cases protect tools perfectly
All products well package with or without labels
Customers requirement lables are accepted
Shipping Time: 5-7 working days
Shipping Method: DHL, UPS, FEDEX, EMS etc
ISO9001:2015,ISO14001:2015
CIMT2019,Beijing,China
